Focal Length 2mm HFOV 96 Degrees Wide Angle lens F2.6 Low Distortion M7 Lens
$3.00
Availability:
In stock
Out of stock
Variations
Product Description
Lens Description
Low Distortion 2mm Wide Angle Lens for 1/4" Sensor
.have M7 and M12 thread size
.Ultra short TTL 10.7mm
.Low distortion <-8%
.HFOV 96 degrees
Lens Specification | |
| Optical format | 1/4" 5mp |
| Focal length (EFL) | 2mm |
| F/NO | F2.6 |
| Back focal length | 3.69mm |
| Field of view (FOV) | DFOV=110 HFOV=90 VFOV=727 |
| Distortion | <-8% |
| TTL | 10.7mm |
| Mount | M7 M12 |
| Diameter | 10mm/14mm |
Lens Spec | |
| Sensor | 1/2.3" MT9F002 |
| EFL | 2.8mm |
| FOV | 124*112*82 |
| TTL | 24mm |
| Distortion | 0.5% |
