4MP Dual Camera Module 1080P VR, Ranging, 3D Reconstruction Vision Application Camera Module
$43.20
Availability:
In stock
Out of stock
Variations
Product Description
Product Parameter
| Product Name | 4mp usb dual camera module |
| Module No | BM4M2214HD-2 V11-100 |
| Module Size | 80mm × 22mm × 18.50mm±0.5MM |
| Product Features | 1. Main performance binocular 1080P high definition 2. Customizable with microphone (Fees) 3. 4M2142HD The baseline of the 4M2214HD two models is 120/60mm, and the other performance configurations are completely the same 4. Defect: Color temperature deviation in left and right binocular images under varying angles of light |
| Temperature (Operation) | -30°C to 70°C |
| Temperature (Stable Image) | 0°C to 50°C |
| Assembly technique | SMT (ROHS) |
| Focus | Fixed |
| Object distance | 30CM-infinity |
| Resolution | 600LW/PH (Center) |
| PCB printing ink | Black |
| interface | USB 2.0 |
| Power suuply | USB bus power |
| supply voltage | DC 5V±5% |
| Maximum Power consumption | 1100 mW |
| Operating system request | Win XP/win 7 8 / vista /android 4.0/ mac /Linux with uvc |
| Sensor | OV4689 (1/3" ) |
| Seneor Package | COB,Bare Die |
| Maximum resolution | 2688*1520 |
| Sensitivity | 1900mV /（lux-sec） |
| Pixel Size | 2µm x 2µm |
| Maximum Image Transfer Rate | MJPEG 1280x480 30FPS / YUY2 1280x480 10FPS MJPEG 2160x1080 30FPS / YUY2 2160x1080 3FPS MJPEG 2560x720 30FPS / YUY2 2560x720 3FPS MJPEG 3040x1520 30FPS / YUY2 3040x1520 1FPS MJPEG 3840x1080 30FPS / YUY2 3840x1080 1FPS MJPEG 3840x1520 30FPS / YUY2 3840x1520 1FPS |
| S/N Ratio | 38.3db |
| Max Dynamic Range | 64.6db |
| Shutter type | Electronic rolling shutter |
| AGC/AEC/Whiter balance | Auto |
| Output Formats | YUY2/MJPEG |
| Microphone | NO |
| Lens Construction | 2G2P |
| F/No | 2.4 |
| EFL | 3.0 mm |
| FOV | 100° |
| TV Distortion | <5% |
| Relative Illumination (Sensor) | 70% |
| IR Filter | 650±10nm |
| Module Package | Anti-electrostatic tray |
| Certifications | FCC/CE/ROHS |
