Raspberry Pi Camera Module OV5647 5MP Wide Angle Raspberry Pi 3/2 Camera Module
$10.20
Availability:
In stock
Out of stock
Variations
Product Description
Product Specification
Module No. | HR3232-175 V11 |
| Module Size | 32mm × 32mm × 26mm |
| Temperature (Operation) | -20°C to 70°C |
| Temperature (Stable Image) | 0°C to 50°C |
| Assembly technique | SMT (ROSH) |
| Focus | Fixed |
| Object distance | 30CM to infinity |
| Resolution | 800LW/PH (Center) |
| PCB printing ink | green |
| interface | 15p-1.0 mip |
| Working power supply | 3.3v（pin15） |
| Operating system | Raspberry Pi |
| Package | Anti-electrostatic tray |
| Certifications | FCC and CE |
| Sensor Type | OV5647 (1/4" ) |
Active Array Size | 2592*1944 |
Sensitivity | 600mV/Lux-sec |
| Pixel Size | 1.4µm x1.4µm |
Maximum Image Transfer Rate | 15 fps for QSXGA; |
| Output formats | 8/10bit RGB RAW output |
S/N Ratio | 34db |
| Dynamic Range | 67db @8x gain |
Package | CSP,Bare Die |
| Lens Type | |
| EFL | 3.6mm |
| DFOV | 175° |
| IR Filter | no |
Detail Images
♦What lens optional you have?
We have normal M12 2.1/2.8/3.6/6/8/12mm lens.
♦What operating system your cameras support?
Android, Windows and Linux System
♦Does the camera support Raspberry Pi? If support Linux Ubuntun system?
Yes, all our usb cameras support Raspberry Pi system and Linux Ubuntun system.
♦Does the camera support OTG?
Most of our usb cameras support OTG function.
♦Which software your usb camera module support?
Blue Iris, ContaCam, Yawcam, Ispy, Motion Eye OS,AMCAP Wecam Viewer, IP Camera Viewer, ZoneMinder,V4L2 video for Linux, Camerafi,
VLC Player
♦Can you supply the USB cable together with camera?
Yes, we supply 40cm/1M usb cable for sample testing. if you need longer usb cable, we can customize it for you. welcome to contact
us in advance.
We have normal M12 2.1/2.8/3.6/6/8/12mm lens.
♦What operating system your cameras support?
Android, Windows and Linux System
♦Does the camera support Raspberry Pi? If support Linux Ubuntun system?
Yes, all our usb cameras support Raspberry Pi system and Linux Ubuntun system.
♦Does the camera support OTG?
Most of our usb cameras support OTG function.
♦Which software your usb camera module support?
Blue Iris, ContaCam, Yawcam, Ispy, Motion Eye OS,AMCAP Wecam Viewer, IP Camera Viewer, ZoneMinder,V4L2 video for Linux, Camerafi,
VLC Player
♦Can you supply the USB cable together with camera?
Yes, we supply 40cm/1M usb cable for sample testing. if you need longer usb cable, we can customize it for you. welcome to contact
us in advance.
