1/2.9" Sony IMX323 2MP 1080P 30fps USB2.0 mic Camera board H.264 YUY2 MJPEG
$37.50
Availability:
In stock
Out of stock
Variations
Product Description
Features
2MP 1080P HD USB camera with 1/2.9" Sony IMX323 Sensor
1/2.9" Sony IMX323 CMOS Sensor
Using H.264, MJPEG, YUY2 three encoding, has a very good indoor and outdoor effects, vivid colors
Support UVC protocol, no driver, plug and play.
Support USB2.0 OTG protocol, OTG access devices.
Support linux, Android and other embedded systems.
Support dual digital MIC, stereo capture quality excellence.
| Product number | |||
| Sensor | Sony IMX323 | ||
| MAX effective pixels | 1920 * 1080 | ||
| Sensor Size | 1/2.9 inch | ||
| Pixel Size | 2.8μm x 2.8μm | ||
| Output parameters | video format | Max Rosolution | Max Frame rate |
| H.264/YUY2/MJPEG | 1080P | 30fps | |
| Min illumination | Color: 0.01 Lux@F1.2; B&W: 0.005 Lux@F1.2 | ||
| focusing | Fixed | ||
| max S/N ratio | 21dB | ||
| dynamic range | 45dB | ||
| Interface type | USB2.0 | ||
| Adjustable parameter | Contrast, Saturation, Sharpness, White Balance, Exposure | ||
| audio Mic | Optional Mono /stereo | ||
| power | USB BUS POWER | ||
| Voltage | DC 5V | ||
| Electric current | Max 300mA | ||
| PCBA Size | 38*38mm / 32*32mm | ||
| Storage temperature | -20°C to 70°C | ||
| working temperature | 0°C to 55°C | ||
| USB Wire rod | Customized | ||
| System support | WinXP/Vista/Win7/Win8/Win10 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC | ||
| Lens | 1/2.7" Construction: 4G+IR FOV: D 130°, H 101°, V 65° Thread: M12*0.5mm Structure: 4G + IRcut | ||
