Cost Effective 2MP 1080P FH8852 1/3" GC2083 USB UVC Camera Module Board
$6.90
Availability:
In stock
Out of stock
Variations
Product Description
1/2.9" 2MP 1080P GC2083 image sensor;
Standard UVC UAC protocol, free driver, plug and play;
Compitable with Windows / Android / Linux OS;
Supports MJPG, YUY2, H.264 compress format, Max 2MP 30fps resolution;
Can be used for online teaching, live broadcast, video conference, video chat, smart TV external equipment
| Imaging Sensor | 1/3" GC2083 |
| Effective pixels | 1920 (H) ×1080 (V) |
| Resolution | 2MP |
| SoC | CPU+ISP Dual core 32bit RISC 750MHz + 32bit RISC 500MHz |
| OS | RTOS |
| Memory | RAM: 64M, ROM: 8MB |
| SNR | >37dB |
| Dynamic Range | 74dB |
| video stream | MJPG: 2560*1440/1920*1080/1280*720/640*480 YUY2: 1280*720/640*480 H.264: 2560*1440/1920*1080/1280*720/640*480 H.265: 2560*1440/1920*1080/1280*720/640*480 |
| Frame rate | 30fps |
| Electronic shutter | auto |
| Protocol | UVC/UAC |
| USB | USB 2.0 |
| Parameters | Brightness, Contrast, Hue, Sharpness, White Balance |
| Protocol | UVC 1.0, UAC 1.0 |
| Audio | Format: PCM sensitivity: -36dB |
| Video output | USB video stream |
| Working voltage | DC5V / 160 mA ±6 mA |
| Working environment | - 20°C ~ 60°C |
| OS compatible | Windows XP/7/8/10/11, Android V5.0 and above (need driver supported) , Linux (need driver supported), MAC 10.10 |
| Software compatible | QQ, Wechat, Dingding, Zoom, MS Teams, Skype, Google Metting, FaceTime for Mac, Faceboot, Youtube, MindLinker, OBS, WeLink, PotPlayer, Ecap etc. |
