Cost Effective 4MP 1440P 1/3" GC4083 Fulhan FH8852V201 USB UVC Camera Module Board
$7.20
Availability:
In stock
Out of stock
Variations
Product Description
13/3" 4MP GC4083 SENSOR
Support multiple video encoding
Support UVC (drive-free protocol)
Support multi-operating system
Support digital wide dynamic
USB microphone
Adaptive digital noise reduction, 2D-DNR,3D-DNR
Support maximum resolution of 2560x1440
Compitable with Windows / Android / Linux OS;
Supports MJPG, YUY2, H.264, H.265 compress format, Max 2560*1440 30fps resolution;
Can be used for online teaching, live broadcast, video conference, video chat, smart TV external equipment
| Imaging Sensor | 1/3.02" GC4083 |
| Effective pixels | 2560 (H) ×1440 (V) |
| Resolution | 4MP |
| S | Fulhan FH8852V201 |
| Min illumination | 0.1Lux @F1.2 (AGC ON) |
| video stream | 2560*1440@30fps 1920*1080 @30fps |
| Audio | Microphone |
| Synchronization | Internal |
| Protocol | UVC/UAC |
| Video Coding | MJPG, YUY2, H.264, H.265, NV12 |
| Working voltage | DC5V / 160 mA ±6 mA |
| Working environment | - 20°C ~ 60°C |
4P Socket | Indicator | MIC | |||
5V | 5V+ Power | RED | Power | + | MIC+ |
DM | Data | GREEN | Working status | - | MIC- |
DP | Date | ||||
G | GND | ||||
