AHD 5MP Camera PCB BSI 1/2.9" Sensor Camera Module Support AHD/TVI/CVI/CVBS 5-15v Power Night Vision HD Security System
$3.80
Availability:
In stock
Out of stock
Variations
Product Description
Product Description
Specification
Model No. | V10 |
Sensor | BSI 1/2.9＂CMOS |
DSP | FH8536H |
System | PAL/NTSC |
Effective Pixel | 8M:3480*2160 12.5/15F 5M:2560*1920 20/12.5F 4M:2560*1440 15/25/30F 2M:1920*1080 25/30F |
Illumination | 0.05Lux@(F1.2,AGC ON)，0LUX with IR |
Shutter | AUTO |
D/N | EXT（Default）/AUTO/COLOR/B/W |
Synchronously | Internal |
Video output | AHD/TVI/CVI/CVBS |
Exposure | BRIGHTNESS / EXPOSURE MODE / GAIN |
BW | ATW/MWB |
D/N | EXT（Default）/AUTO/COLOR/B/W |
Video Setting | Contrast/Sharpness/COLOR GAIN/DNR/Format/DWDR |
Language | ENG/CHN1/ESP/FRA/CHN2/ RUS/ITA /POL/POR /KRO |
Reset | Support |
Operation Temperature | -20℃ to 60℃ |
Working Humidity | Relative humidity less than 90 % |
Power | DC12V(±20%) - 65mA |
Size | 32*32/38*38（mm) |
