4K 8MP HD IP Camera Module CCTV IP Camera Module Customized USB Camera Module
$9.20
Availability:
In stock
Out of stock
Variations
Product Description
Product Description
Specification
Model No. | PB1 | |
Module | FH8856V100+1/3" GC8053 | |
LUX | COLOR 0.05Lux@F1.2; B/W 0.005Lux@F1.2; | |
S/N | ≥50db(AGC OFF) | |
WDR | DWDR; ＞80db | |
Audio Input | 1CH MIC Input | |
Audio Output | 1CH Output, Speaker Optional | |
IO port | 1CH RESET | |
SD card | Not support now | |
WIFI | NO | |
Main Steam | 3840*2160 , 5-15FPS/S; 2592*1944 , 5-20FPS/S | |
Main Steam | 2560*1440、2304*1296、1920*1080、1280*720, 5-25 FPS/S | |
Sub steam | 704*576、640*480、640*360、352*288, 5-25FPS/S | |
Sub steam | 2560*1440、2304*1296、1920*1080、1280*720, 5-25 FPS/S | |
Video Coding Compression | 128Kbps-8192bps continuous adjustable | |
Image Adjustment | Brightness, contrast, saturation, sharpness | |
Subtitle Overlay | Support Channel Name、Date & Time .5 groups of characters superposition adjustable | |
Data Record | Video,picture | |
Storage Method | Cycling Recording, Alarm Recording | |
Alarm Transfer | IO output, browser, management software | |
Protocol | All Net Connect / ONVIF 2.6 | |
Mobile | Support IOS, Android | |
Browser | Support IE6.0 and above browser Client Browser | |
Temperature | -20℃ - +60℃ | |
Humidity | 0% - 90% | |
Power | DC12V /POE | |
power | 1.5W | |
size | 38* 38*10mm (without lens) | |
Weight | 0.06kg |
