CCTV 3MP IP Camera Module Hote Sale Camera PCB Board from Shenzhen China
$4.50
Availability:
In stock
Out of stock
Variations
Product Description
Product Description
Specification
Model No. | H30 |
Module | Fullhan 1.5K DSP+1/4'' 3MP |
LUX | Color 0.1Lux@F1.2;B/W 0.01Lux@F1.2 |
S/N | ≥50db(AGC OFF) |
WDR | DWDR; >80db |
Audio Input | Audio MIC Input |
Audio Output | 1CH Outout Speaker Optional |
LED TYPE | CDS IR LED & Warm LED & White LED(Support PWM) |
IO Function | IR CUT & 1CH Reset & Alarm In & Alarm Out |
Others | Extra Motorized Zoom Auto Focus Lens Optional |
Coding Format | H.264 |
Main Steam | 2304*1296 |
Sub Steam | 704*576,8001*448,640*480,640*360,352*288 |
Video Coding Compression | 128Kbps-8192bps Continuous Ajustable |
Subtitle Overlay | Support Channel Name&Date&Time&Resolution&4 lines Characters adding |
Data Record | Video & Picture |
Storage Method | Cycling Recording & Alarm Recording |
Alarm Transfer | IO output & Browser & Management Software |
Protocol | Standard ONVIF Protocol |
Mobile | Support IOS & Android |
Browser | Support IE6.0 and above browser(insert Web Server) |
Operation Temperature | -30℃ to +60℃ |
Humidity | 0%-90% |
Power | DC12V/90mA |
Power | 1.1W |
Size | 38*38*10mm(without lens) |
Weight | 10g |
