4MP 4IN1 AHD/TVI/CVI/CVBS Camera Module Support UTC with 2DNR
$6.90
Availability:
In stock
Out of stock
Variations
Product Description
Features:
l Use GC4653 4MP CMOS,captured moving images.
l Support 4 in 1 Coaxial high-definition output, with excellent performance, clear and bright picture
l Lux: 0.02Lux@(F1.2,AGC ON),0LUX with IR
l Support IR-CUT,CDS external control , D/N,
l Support OSD and Customization
l Adaptive Digital Noise Reduction,2D-DNR
l Support UTC
Spec:
Model Spec | F3853-V1 | |
4MP 4in 1 coaxial high-definition CCTV camera Module | ||
Detailed Specifications | ||
Sensor | 1/3.2" GC4653+FH8538M | |
System | PAL/NTSC | |
Effective pixels | 2576(H)x1440(V) | |
Illumination | 0.02Lux@(F1.2,AGC ON),0LUX with IR | |
Shutter | AUTO | |
D/N | EXT(Default)/COLOR/B/W | |
Synchronously | Internal | |
FPS | 4MP@25fps / 4MP@30fps | |
Video output | AHD/TVI/CVI/CVBS (Optional) | |
OSD menu | ||
Exposure | BRIGHTNESS /EXPOSURE MODE /GAIN | |
BW | ATW/MWB | |
D/N MODE | Infrared/COLOR/B&W | |
Video Setting | Contrast/Sharpness/COLOR GAIN/DNR | |
Language | CHINESE/ENGLISH | |
Reset |
| |
Common | ||
Operation Temperature | -20℃ to 60℃ | |
Operation humidity | Relative humidity less than 90 % | |
Power | DC12V(±20%) - 60MA | |
Dimension | 32*32/38*38(mm) | |
