Hisilicon DSP Hi3516D Digital Sony IMX290 IMX291 Sensor IP CCTV Board Camera PCB Module
$45.00
Availability:
In stock
Out of stock
Variations
Product Description
Product Description
Specification
Model No. | IPC-S290-V1（200W resolution） |
Hardware | |
Module | Hi3516D，1/2.8” SONY 290 COMS snesor |
LUX | Color 0.001Lux@F1.2 |
S/N | ≥50dB(AGC OFF) |
WDR | WDR ；＞120db |
Port | |
Audio/Intercom Input | 1CH MIC Input/linear input |
Audio Output | 1CH output |
IO port | 1CH RESET |
CVBS Output | Support 1CH CVBS output |
I/O input/output | Suppot 1CH alarm input,1CH alarm output |
IO function port | 1CH reset(optional: reset、alarm input、alarm output) |
RS485 | Support one RS485 port |
USB port | Support 1 USB port,support a 64G USB,support WIFI |
Video Coding | |
Coding Format | H264，Baseline/Main Profile/High Profile Coding；H.265 Main Profile Coding, MJPEG |
Main Steam | 1920*1080，1-25(30)FPS |
Main Steam | 1280*720，1-25(30)FPS |
Sub steam | 704*576，1-25(30)FPS 640*480，1-25(30)FPS |
Sub steam | 640*352，1-25(30)FPS 320*240，1-25(30)FPS |
Video Coding Compression | 32Kbps-16Mbps continuous adjustable，support CBR/VBRs-1 |
Subtitle Overlay | Support channel name、Date、Code stream information overlay,Overlay place adjustable |
Data Transmission &Storage | |
Data Record | Video,picture |
Storage Method | Manual、auto(cycle、fixed time、alarm switch、motion detection) |
Alarm Transfer | FTP、E-mail, browse, management software |
Protocol | TCP/IP、UDP、RTP、RTSP、RTCP、HTTP、DNS、DDNS、DHCP、FTP、NTP、PPPOE、SMTP、UPNP |
Browser | Support IE6.0 and above browser Client Browser |
Supply power | DC12V 1A/POE（ External POE module ） |
power | 3W(MAX) |
Size | 38(L) * 38(W) *20(H)mm(without lens ) |
IR-CUT hole | 22mm |
weight | 0.15kg |
